2508.04651

# Live Music Models **Authors**: Lyria Team, Google DeepMind111See Contributions and Acknowledgments section for full author list ## Abstract We introduce a new class of generative models for music called live music models that produce a continuous stream of music in real-time with synchronized user control. We release Magenta RealTime, an open-weights live music model that can be steered using text or audio prompts to control acoustic style. On automatic metrics of music quality, Magenta RealTime outperforms other open-weights music generation models, despite using fewer parameters and offering first-of-its-kind live generation capabilities. We also release Lyria RealTime, an API-based model with extended controls, offering access to our most powerful model with wide prompt coverage. These models demonstrate a new paradigm for AI-assisted music creation that emphasizes human-in-the-loop interaction for live music performance. Magenta RealTime (Open): github.com/magenta/magenta-realtime Lyria RealTime (API): g.co/magenta/lyria-realtime footnotetext: See Contributions and Acknowledgments section for full author list. ## 1 Introduction Music exists in two complementary forms: as static recorded pieces (“music as a noun”), and as live performances collectively experienced in real time (“music as a verb”) [1]. This second form of live music is particularly tied to the fundamental human experiences of creative flow [2, 3], embodied expression [4], and social connection [5]. Despite this, modern generative AI systems for musical audio have had an overwhelming emphasis on offline, turn-based generation [6, 7, 8, 9, 10, 11, 12, 13, 14, 15]. Live music represents a new frontier for generative AI, one with numerous opportunities and technical challenges. In the conventional offline setting, users input control information, wait $L$ seconds (offline latency), and receive $T$ seconds of audio. In our proposed live setting, users continuously input control information, receiving $T$ seconds of an uninterrupted audio stream from $T$ seconds of interaction, with $D$ seconds of delay between their control inputs and their influence on the audio stream. Placing users in a continuous perception-action loop promotes more active creation, creates higher-bandwidth interaction, fosters personalized expression and emphasize the process as much as the product. However, meeting these rigid synchronization requirements while maintaining high quality audio generation is a challenging task for machine learning models. Some offline music generation systems [16] have a Real Time Factor (RTF) r $≥ 1×$ , i.e., they generate $T$ seconds of audio with latency $L≤ T$ . RTF is commonly defined as both $L/T$ and $T/L$ . Here we use $T/L$ , i.e., higher RTF means faster. However, most are not well-suited for live performance, as they lack other necessary attributes. Specifically, we differentiate live music models as those which have all three of the following attributes: (1) real-time generation with throughput RTF $≥ 1×$ , (2) causal streaming where audio generates continuously as a function of both user control inputs and past audio output, and (3) responsive controls (delay $D$ is low, facilitating live interaction). Open-weights models are particularly well-suited for live generative music because they can run locally on users’ devices. On-device inference has numerous benefits in music [17], enabling (1) lower latency by eliminating network requests, (2) higher reliability, facilitating usage in real-world contexts, (3) privacy guarantees, and (4) customization by artists. Cloud-based APIs address complementary use cases, offering access to models running on specialized hardware that are more powerful than those that would run on edge devices, at the cost of some of the benefits of open-weights models. To allow users to navigate these tradeoffs based on their application goals, we introduce a pair of systems that span both paradigms: Magenta RT (open-weights, on-device) and Lyria RT (API, cloud-based). Both use the same core methodological framework, which centers around codec language modeling [18, 19] (Figure 1). Specifically, we train a language model (LM) to generate audio tokens from SpectroStream [20], using a method similar to [21, 22] to achieve live streaming [23]. We focus our subsequent discussion primarily on Magenta RT, which may be of higher interest to the AI research community for its ability to be finetuned with new controls [24] or explored for transfer learning [25]. Magenta RT offers first-of-its-kind live generation among open-weights models. On automatic metrics of music quality, it outperforms existing offline open-weights music generation models like MusicGen (Large) [9] and Stable Audio Open [14]. Moreover, Magenta RT uses $38$ % fewer parameters ( $750$ M) than Stable Audio Open ( $1.2$ B), and $77$ % fewer than MusicGen Large ( $3.3$ B). Along with our codebase and model weights, we release a set of demos that run in real time on free-tier Colab TPUs (v2-8) and showcase three distinct use cases: live generation, finetuning, and a novel live audio input interaction that we call audio injection (Section 4.2). Audio samples and links to code, weights and demos are provided in the online supplement: https://storage.googleapis.com/live-music-models/index.html <details> <summary>x1.png Details</summary>  ### Visual Description ## Diagram: Audio Generation System Architecture ### Overview The diagram illustrates a real-time audio generation system that combines text prompts, audio context, and language model processing. It features a bidirectional encoder-decoder architecture with residual vector quantization (RVQ) for audio representation, weighted text prompts for instrument control, and a user interface for spectrogram visualization. ### Components/Axes 1. **Core Architecture**: - **LM Encoder-Decoder**: Contains: - Bidirectional Encoder (blue) - Causal Decoder (dark blue) - **RVQ Processing**: - Coarse RVQ (4 depth, 10s/5 chunks) - Generated Chunk (16 depth, 2s) - **Text Prompts**: - Music CoCa (blue) - Joint Text-Music Embed (red) - Weighted Text Prompts (deep house, djembe, saxophone) 2. **User Interface**: - Spectrogram Stream visualization - Audio Decoder output 3. **Temporal Flow**: - Loops every 2 seconds - Context window: 10 seconds (5 chunks) - Output chunk: 2 seconds ### Detailed Analysis - **Style Tokens**: - 2 pink tokens (⚫) representing audio style - 5 gray tokens (⚫) for previous audio context - 4 yellow tokens (⚫) for current chunk - **RVQ Depth Progression**: - Input: 4 depth (coarse) - Output: 16 depth (fine) - Indicates 4x increase in audio resolution - **Text Prompt Weights**: - Deep house: 70% (⚫) - Djembe: 20% (⚫) - Saxophone: 10% (⚫) - Weighted average (⚫) shown as combined input - **Temporal Parameters**: - Processing interval: 2 seconds - Context window: 10 seconds (5×2s chunks) - Output resolution: 16× finer than input ### Key Observations 1. **Bidirectional Processing**: The encoder captures both past and future context, while the decoder generates sequentially 2. **Resolution Scaling**: 4x increase in RVQ depth suggests significant audio quality enhancement 3. **Instrument Control**: Text prompts allow precise control over musical elements 4. **Real-time Constraints**: 2-second processing interval implies low-latency operation 5. **Context Window**: 10-second lookback enables coherent audio generation ### Interpretation This architecture demonstrates a sophisticated audio generation pipeline that: 1. **Integrates Multimodal Inputs**: Combines text prompts (Music CoCa) with audio context for coherent generation 2. **Optimizes Computational Efficiency**: Uses coarse RVQ for context and fine RVQ for output 3. **Enables Real-time Interaction**: 2-second processing loop with spectrogram feedback 4. **Supports Musical Creativity**: Weighted text prompts allow precise instrument control 5. **Maintains Temporal Coherence**: Bidirectional encoder ensures context awareness while causal decoder preserves sequence integrity The system appears designed for interactive music creation or real-time audio synthesis applications, balancing quality (16-depth RVQ) with responsiveness (2s processing). The 4x RVQ depth increase suggests a focus on high-fidelity output despite coarse input representation. </details> Figure 1: Magenta RealTime is a live music model that generates an uninterrupted stream of music and responds continuously to user input. It generates audio in two-second chunks using a pipeline with three components: (1) MusicCoCa, a style embedding model, (2) SpectroStream [20], an audio codec model, and (3) an encoder-decoder language model. For each chunk, a style embedding is computed via a weighted average of MusicCoCa embeddings of text and audio prompts from the user. Given this style embedding and $10$ seconds ( $5$ chunks) of past audio context, the language model decoder generates SpectroStream audio tokens for the new chunk, which is then decoded to audio. ## 2 Method Magenta RT is a codec language model [18, 19] designed to generate high-fidelity stereo audio in real time based on acoustic style conditioning. To achieve this, we adopt a pipeline-based approach, using an encoder-decoder Transformer [26] to model audio tokens from SpectroStream [20] conditioned on style embeddings from our proposed MusicCoCa (Figure 1). See Appendix A for related work. ### 2.1 Audio Tokenization via SpectroStream Codec language modeling involves the use of a discrete audio codec to convert audio data into language-like tokens. A codec is a pair of functions, an encoder and decoder, that convert audio to and from a compressed space with minimal perceivable distortion. More formally, the encoder component Enc is a function mapping raw stereo audio waveforms $a∈ℝ^Tf_s× 2$ into sequences of discrete tokens ${V_c^Tf_k× d_c}$ , where $T$ is the duration in seconds, $f_s$ the audio sampling rate, $V_c$ the codec vocabulary, $f_k$ the token frame rate, and $d_c$ the RVQ depth. The decoder module $\texttt{Dec}≈eq\texttt{Enc}^-1$ then performs the approximate inverse operation to reconstruct the waveform given the compressed representation, ensuring that the process is as perceptually lossless as possible. Here we adopt the recently proposed SpectroStream codec [20], a full-band ( $f_s=48$ kHz) multi-channel neural audio codec based on residual vector quantization (RVQ) [27], with an overall bandwidth of $16$ kbps ( $f_k=25$ Hz, $d_c=64$ , $|V_c|=1024$ ). To facilitate live streaming, we reduce the bandwidth to $4$ kbps by generating only the first $16$ RVQ levels (coarse and medium from Figure 3), yielding a live throughput target of $400$ tokens per second. See Section C.1 for more details. ### 2.2 Style Embeddings via MusicCoCa We use a joint audio-text representation as a control mechanism for overall audio style. This is achieved by training a joint audio-text embedding model on music annotated with diverse textual descriptions. The text encapsulates musical characteristics useful for high-level control, which we collectively refer to as style (Section 4.1). Our embedding model, MusicCoCa, builds upon MuLan [28] and CoCa [29]. It is a contrastive captioner (CoCa) consisting of two embedding towers, mapping each modality to a shared $768$ -dimensional space. The audio embedding tower $M_A$ is a $12$ -layer VisionTransformer (ViT) [30]. Its input is a log-mel spectrogram of a $10$ s slice of $16$ kHz audio ( $128$ channels and length $992$ ; split into patches of size $16× 16$ ). The text embedding tower $M_T$ is a $12$ -layer Transformer, which operates on tokenized text with a maximum sequence length of $128$ tokens. We use attention pooling to reduce the activations of each tower to a single $768$ d embedding, which can be subsequently quantized into $12$ discrete tokens with codebook size $|V_m|=1024$ . This tokenized representation (of audio or text) is then used as a conditioning signal in the LM encoder. Variable-length audio of duration $T$ may be embedded by zero padding to a multiple of $10$ seconds and then mean pooling across $\lceil\frac{T}{10}\rceil$ chunks. In addition to the two embedding towers, MusicCoCa has a text decoder which can generate audio text captions. In our application this decoder is a shallow 3-layer Transformer which only serves a regularizing purpose. The MusicCoCa optimization objective, based on the CoCa framework [29], consists of contrastive and generative loss components which we weigh equally. We train the model using the Adafactor optimizer with a learning rate of $1× 10^-4$ and $1{,}000$ warmup steps for a total of $16{,}000$ steps. The batch size is $1024$ . ### 2.3 Modeling Framework Magenta RT operates on audio tokens from a discrete audio codec, following an established practice in audio modeling [18, 31, 8, 9]. Our model autoregressively predicts discrete audio tokens conditioned on both preceding audio and a shared audio-text embedding. This modeling mechanism partly mirrors the MusicLM architecture [8], itself based on AudioLM [31]. Similarly to MusicLM, we use a Transformer-based architecture [26] for the token prediction model and enable text conditioning by leveraging a joint audio-text embedding model, using the target audio signal at training time, and text inputs at inference time. To facilitate live generation, we propose two high-level changes relative to MusicLM: (1) we replace the hierarchical cascade of multiple LMs with a single LM, using a recent method [23] similar to [21, 22] for efficiency, and (2) we propose a chunk-based autogressive approach to allow for infinite streaming generation. More formally, given audio $a$ , our goal is to model the probability ${P_θ(\texttt{Enc}(a)\mid M_A(a))}$ of the corresponding sequence of acoustic tokens given its associated style embedding. Here, Enc denotes the audio codec encoder and $M_A$ the MusicCoCa audio encoder. At inference, we sample from the model $e\prime∼ P_θ(·\midc)$ , conditioning on a style embedding $c$ obtained from an arbitrary mixture of audio and text prompts. Finally, we use the codec decoder to produce output audio, i.e., $a\prime=\texttt{Dec}(e\prime)$ . #### 2.3.1 Chunk-based autoregression with coarse context In the live generation setting, we require our model to generate an infinite and uninterrupted stream of audio with a RTF $≥ 1×$ . To achieve this, we propose two key techniques: chunk-based autoregression to enable infinite streaming, and the use of coarser RVQ tokens in the audio history. In order to generate an infinite stream of audio, at inference time we must be able to predict an audio sequence with a length likely larger than what the model has seen during training. Such a mismatch in sequence length between training and inference is often found to result in unpredictable behavior and degraded performance [26, 32]. Previous work has addressed this issue via sliding attention windows with a relative positional encoding scheme [33, 34], informing the model about the relative distance between tokens instead of describing their absolute position within the sequence. We instead propose chunk-based autoregression, where we operate on chunks of length $C=2$ seconds, and, under a Markov assumption, predict each chunk based on a limited context of $H=5$ previous chunks ( $10$ seconds of history). This has several advantages: it reduces error accumulation and allows for stateless inference, eliminating the need to maintain a generation cache and simplifying model deployment. It also introduces flexibility during sampling, since conditioning is updated between calls without preserving information about controls beyond the context window. To achieve RTF $≥ 1×$ , we also propose to use a coarse representation of the audio context. Due to the hierarchical structure of RVQ, lower quantization levels capture the most salient acoustic information. While generating target tokens at the full RVQ depth ( $d_c=16$ ) is crucial to maintaining high fidelity, a lower resolution may be sufficient to represent the audio history. Therefore, we use a coarser representation consisting of the first $4$ RVQ tokens for conditioning on the previous chunks. More formally, a chunk is a contiguous segment of audio tokens representing $C$ seconds of audio. For audio $a$ , we define $\texttt{Chunk}_i\triangleq\texttt{Enc}(a)_Cf_{ki:Cf_k(i+1)}$ , i.e., the span of tokens representing audio between $Ci$ and $C(i+1)$ seconds and including the first $16$ RVQ tokens for each frame. We also define $\texttt{Coarse}_i$ as the first $4$ RVQ tokens over the same span of time. Our de facto modeling objective is thus $P_θ(\texttt{Chunk}_i\mid\texttt{Coarse}_i-H:i,c_i)$ , where $c_i=\texttt{Quantize}(M_A(a)_\lfloor\frac{Ci{10}\rfloor})$ is $12$ tokens representing the most recent quantized MusicCoCa audio embedding for chunk $i$ . ### 2.4 Encoder-Decoder Language Model To model this distribution, we use an encoder-decoder Transformer [26] LM trained with T5X [35, 36]. We release pre-trained models using the T5 [35] Base and Large configurations. Encoder The bidirectional encoder is responsible for processing the acoustic history and style control into an intermediate representation for generation. At chunk $i$ , the encoder receives the concatenation of the acoustic history and style tokens ${x_i=\texttt{Coarse}_i-H⊕\dots⊕\texttt{Coarse}_i-1⊕c_i}$ , with a total length of $1012$ tokens ( $4· C· H· f_k=1000$ audio + $12$ style tokens) and a vocabulary unified across the codec and quantized style tokens $V=\{\texttt{<S>},\texttt{<P>}\}∪V_c∪V_m$ . Decoder A key differentiating factor compared to prior work is our imposed constraint of achieving RTF $≥ 1×$ generation to enable live interactive applications. Past work such as MusicLM [8] proposes a hierarchical cascade of language models to model tokens efficiently, while MusicGen [9] proposes a delay pattern—neither approach would achieve RTF $≥ 1×$ for full bandwidth audio tokens. Instead, based on [23], our decoder comprises two connected Transformer modules. The “temporal” module constructs a temporal context by processing acoustic frames, where RVQ tokens within each frame are embedded and aggregated to yield a single frame-level embedding. The “depth” module then performs autoregressive prediction of the RVQ indices conditioned on the previous temporal context. With this setup, we achieve RTF= $1.8$ on H100 GPU with the T5 Large configuration. ## 3 Experiments Live music models enable new types of interaction that are best assessed via direct human evaluation and extensive use. As such, many of our design choices were validated through play testing by team members and partner musicians, optimizing for how expressive and engaging the resulting instrument feels. A formalization of this interactive evaluation is presented in our user study in Appendix F. We complement this subjective measure with more constrained experiments to examine the effects of our controls and provide comparisons to existing models where possible. We focus these experiments on assessing core capabilities that are common to both live and offline music audio generation models, such as audio quality and adherence to text conditioning (Section 3.2.1), alongside others that are unique to our live music models, such as the ability to generate musical transitions following changes in the conditioning signal (Section 3.2.2). In addition to our evaluation, we also note that, at the time of writing, Magenta RT is ranked as the top open-weights model on the Music Arena leaderboard [37], based on over 1k real-world user preferences. ### 3.1 Experimental Set-up Training We pretrain the LM at Base (220M parameters) and Large (770M parameters) size. The dataset comprises around $190{,}000$ hours of primarily instrumental stock music sourced from various providers. Each training example consists of a $12$ -second audio clip randomly sampled from the raw data, structured as $10$ -second context tokens and $2$ -second target tokens. MusicCoCa tokens are derived from the target audio, of which the first $6$ RVQ levels are used for training. To mitigate the cold-start issue in streaming, we replace early context tokens with variable-length padding tokens. Each model is trained for $1.86$ million steps using the Adafactor optimizer with batch size of $512$ and an inverse square root learning rate schedule with $10{,}000$ warmup steps. We use TPU-v6e (Trillium) hardware, with $128$ chips for the Base model and $256$ chips for the Large. Sampling parameters For inference, prompts (text or audio) are embedded and tokenized by MusicCoca using the first $6$ RVQ levels to match training. We sample with classifier-free guidance (CFG) [38, 39, 40], using a temperature of $1.3$ , a top-K of $40$ , and a CFG weight of $5.0$ . ### 3.2 Results Table 1: Instrumental music generation results on the Song Describer Dataset [41]. We compare to open models, using a fixed length of $47$ s for all samples, though our models are capable of arbitrary-length generation. For all prior models, we report results from [14]. | Model | Live | Sample rate | Params | FD ${}_openl3↓$ | KL ${}_passt↓$ | CLAP ${}_score↑$ | | --- | --- | --- | --- | --- | --- | --- | | Magenta RealTime | ✓ | 48 kHz | 760M | 72.14 | 0.47 | 0.35 | | Stable Audio Open [14] | ✗ | 44.1 kHz | 1.1B | 96.51 | 0.55 | 0.41 | | MusicGen-stereo-large [9] | ✗ | 32 kHz | 3.3B | 190.47 | 0.52 | 0.31 | #### 3.2.1 Audio quality and adherence to fixed text prompts In this section, we compare Magenta RT to prior work under the offline text-to-music generation setting, where we keep the text conditioning fixed and sequentially generate chunks of audio up to a target length of $47$ seconds. While our model can generate audio of arbitrary length, we choose this duration for a fair comparison between models. Following the evaluation protocol in [14], we then assess the quality and text adherence of the resulting generations using three established metrics, the Fréchet Distance based on OpenL3 embeddings [42] (FD openl3), the Kullback–Leibler divergence (KL passt) and CLAP score. We show the results in Table 1. Magenta RT has the lowest FD openl3 and KL passt scores, indicating that the generated audio is plausible and closely matches the eval reference audio, including at the level of semantic correspondence [14]. The CLAP score measures how well generated audio adheres to the specified text prompt. On this metric, Magenta RT scores between the other two models. The higher score of Stable Audio Open may be related to the fact that their model uses CLAP embeddings during training, as opposed to our model which trains using MusicCoCa. #### 3.2.2 Generating musical transitions <details> <summary>x2.png Details</summary>  ### Visual Description ## Line Graphs: Cosine Similarity Over Time with Different Prompts ### Overview The image contains two line graphs comparing cosine similarity over time (in seconds) for three different prompts: Prompt A (blue), Prompt B (red), and Transition Prompt (orange). The left graph shows overlapping trends for Prompt A and B, while the right graph isolates the Transition Prompt's performance. Shaded regions around each line indicate variability or confidence intervals. --- ### Components/Axes - **Left Graph**: - **X-axis**: "Seconds" (0–50), linear scale. - **Y-axis**: "Cosine Similarity" (0.0–0.5), linear scale. - **Legend**: Located at the bottom-right corner, labels: - Blue line: "w/ Prompt A" - Red line: "w/ Prompt B" - **Shaded Areas**: Gray regions around each line (likely representing standard deviation or confidence intervals). - **Right Graph**: - **X-axis**: "Seconds" (0–50), linear scale. - **Y-axis**: "Cosine Similarity" (0.0–0.5), linear scale. - **Legend**: Located at the bottom-right corner, label: - Orange line: "w/ Transition Prompt" - **Shaded Area**: Light orange region around the line. --- ### Detailed Analysis #### Left Graph (Prompt A vs. Prompt B) 1. **Prompt A (Blue Line)**: - Starts at ~0.45 at 0 seconds. - Decreases steadily to ~0.35 at 50 seconds. - Shaded area widens slightly between 20–40 seconds, indicating increased variability. 2. **Prompt B (Red Line)**: - Starts at ~0.1 at 0 seconds. - Increases steadily to ~0.35 at 50 seconds. - Shaded area remains narrow throughout, suggesting stable performance. 3. **Intersection**: - The blue and red lines cross near **30 seconds**, where both reach ~0.35 cosine similarity. #### Right Graph (Transition Prompt) 1. **Transition Prompt (Orange Line)**: - Starts at ~0.4 at 0 seconds. - Dips to ~0.35 at ~20 seconds. - Rises to ~0.4 by 50 seconds. - Shaded area is narrowest at the dip (20–30 seconds) and widens slightly at the start/end. --- ### Key Observations 1. **Prompt A vs. Prompt B**: - Prompt A shows a consistent decline in cosine similarity over time. - Prompt B demonstrates a steady improvement, surpassing Prompt A after ~30 seconds. - The intersection at 30 seconds suggests a critical point where Prompt B becomes more effective. 2. **Transition Prompt**: - Exhibits a temporary dip in performance (~20–30 seconds) before stabilizing. - The shaded area indicates lower variability during the dip, possibly due to a controlled transition phase. 3. **Shaded Regions**: - Prompt A’s wider shaded area (20–40s) implies greater uncertainty in its performance during this interval. - Transition Prompt’s narrowest shaded region aligns with its lowest cosine similarity, suggesting reduced variability during the dip. --- ### Interpretation - **Prompt Effectiveness**: Prompt B outperforms Prompt A over time, with a clear crossover at 30 seconds. This may indicate that Prompt B is better suited for longer-term tasks or scenarios requiring sustained similarity. - **Transition Prompt Behavior**: The dip in cosine similarity could represent a calibration or adjustment phase, after which performance stabilizes. The narrow shaded area during the dip suggests this phase is predictable or controlled. - **Variability**: Prompt A’s wider confidence intervals (20–40s) highlight instability, whereas Prompt B and Transition Prompt show tighter variability, implying more reliable outcomes. This analysis suggests that prompt design significantly impacts performance metrics over time, with Prompt B and Transition Prompt offering more stable or adaptive results depending on the task phase. </details> Figure 2: Prompt transition evaluation. Over $60$ s, we transition from embeddings of text prompt A to B by stepwise linear interpolation. Left: Cosine similarity compared to the initial (blue) and final (red) text embedding. Right: Cosine similarity to the interpolation between text embeddings provided to the model. In both plots, lines indicate the mean and shaded regions the standard deviation. Live music models unlock the capability of responding dynamically to user inputs. To test this, we create a prompt transition evaluation. We pick pairs of text prompts and task the model with creating musical transitions between them. We linearly interpolate between MusicCoCa text embeddings of the start and end prompt over $60$ seconds ( $6$ steps, $10$ seconds $/$ step), and use this as style conditioning. We then measure cosine similarity between the audio embedding of the outputs and the conditioning embedding at that time. We perform transitions for $128$ prompt pairs (Appendix G). As seen in Figure 2 Magenta RT outputs maintain strong similarity to the target embedding throughout the transition (right panel), and effectively transitions from the initial to final prompt (left panel). The audio context conditioning lead to smooth transitions that blend styles by preserving elements of the initial prompts. While this leads to lower similarity at end of transition and a slight dip in mid-transition similarity, it also lets the music continuously evolve in a smooth and coherent way, and makes the time history of prompts an important and expressive part of performance. ## 4 Controllable Generation ### 4.1 Style Conditioning via Text and Audio During inference, we can create a target conditioning vector $c$ by computing a weighted average of the MusicCoCa embeddings corresponding to $N$ control prompts, provided as either text or audio $c=∑_i=1^Nw_iM(c_i)/∑_iw_i$ , where $w_i$ controls the weight of each prompt. One advantage of using MusicCoCa embeddings instead of attending to text captions is the ability to perform embedding arithmetic to blend styles—e.g., a weighted sum of embed $($ “techno” $)$ and embed $($ “flute” $)$ gives a good approximation of embed $($ “techno flute” $)$ —while also controlling the relative influence of each concept. Beyond this, a shared audio-text embedding space for conditioning allows for the use of audio prompts as a more direct way of achieving a specific musical style or instrumentation that may be difficult to express via text. Since audio prompts more closely match the training setting, where style conditioning is obtained from the target audio itself, this type of prompting is also expected to be more effective. Furthermore, we are able to mix multiple audio prompts to achieve interpolations of different styles, or mix combinations of text and audio prompts. Overall, this type of conditioning offers control over high-level characteristics such as genre, style, instrumentation, mood. ### 4.2 Audio Injection To allow users to continuously steer generation via a live audio stream, we propose an audio steering mechanism we call audio injection. At each generation step, we mix the user’s input audio with the model’s output, tokenize the resulting mix, and feed this as the context for the next generation. This is illustrated in Figure 7. Note, user audio is never played back directly. Rather, the model predicts the continuation of a past context that includes the user audio. Depending on the specific audio injected and the target style, the model may “choose” to repeat or transform the user audio, or may be influenced by its features (dynamics, melody, harmony). See Appendix E for details. ## 5 Conclusion In this work, we introduced live music models, a new class of generative systems designed for real-time, continuous music creation with synchronized user control. We presented two such systems: Magenta RealTime, a fully open-weights model, and Lyria RealTime, an API-based model with extended controls. These models facilitate a novel paradigm for AI-assisted music, emphasizing interactive, human-in-the-loop performance that prioritizes the creative process over just the end product. With future work, we aim to further decrease the control latency to unlock new interactive possibilities. Ultra-low latency could enable direct MIDI or audio control, akin to a new class of synthesizer or audio effect. Further, training on multi-stem audio would open the possibility for models to act as musical partners, jamming along with users and providing dynamic live accompaniment. ## Contributions and Acknowledgments Within each Bolded Category of contribution type, contributors are listed alphabetically. ### Tech Leads Adam Roberts Chris Donahue Kehang Han ### Core Contributors Antoine Caillon Brian McWilliams Cassie Tarakajian Ian Simon Ilaria Manco Jesse Engel Noah Constant Timo I. Denk Yunpeng Li ### Contributors Alberto Lalama Andrea Agostinelli Cheng-Zhi Anna Huang Ethan Manilow George Brower Hakan Erdogan Heidi Lei Itai Rolnick Ivan Grishchenko Manu Orsini Matej Kastelic Mauricio Zuluaga Mauro Verzetti Michael Dooley Ondrej Skopek Rafael Ferrer Savvas Petridis Zalán Borsos ### Lyria RealTime API Doug Fritz Ivan Solovyev Jingjing Xie Matthew Tang Olivier Lacombe Peter Morgan ### Magenta RealTime Release Gus Martins Paige Bailey Omar Sanseviero Tris Warkentin ### Product Management Jeff Chang Hema Manickavasagam Myriam Hamed Torres ### Legal Austin Tarango Phoebe Kirk ### Program Management DY Kim Mahyar Bordbar Moon Park ### Executive Sponsors Aäron van den Oord Douglas Eck Eli Collins Jason Baldridge Tom Hume ### Acknowledgements Many thanks to the entire Lyria team for their support and feedback. Special thanks and acknowledgment to Alex Tudor, Arathi Sethumadhavan, Arturas Lapinskas, Ashu Desai, Beat Gfeller, Cătălina Cangea, Chris Deaner, Christian Frank, Colin McArdell, Damien Vincent, Eleni Shaw, Julian Salazar, Kazuya Kawakami, Marco Tagliasacchi, Matt Sharifi, Michael Chang, Reed Enger, RJ Skerry-Ryan, Ron Weiss, Sander Dieleman, Sertan Girgin, Tancred Lindholm, Tobenna Peter Igwe, Victor Ungureanu, and Yotam Mann. Additional thanks to Chris Reardon, Mira Lane, Koray Kavukcuoglu, and Demis Hassabis for their insightful guidance and support throughout the research process. MusicFX DJ was the first deployment of Lyria RealTime and developed in collaboration with our partners from Google Labs including Obed Appiah-Agyeman, Tahj Atkinson, Carlie de Boer, Phillip Campion, Sai Kiran Gorthi, Kelly Lau-Kee, Elias Roman, Noah Semus, Trond Wuellner, Kristin Yim, and Jamie Zyskowski. We give our deepest thanks to Jacob Collier, Ben Bloomberg, and Fran Haincourt for their valuable feedback throughout the development process. We also acknowledge the many other individuals who contributed across Google DeepMind and Alphabet, including our partners at Envisioning Studio and YouTube. ## References - Small [1998] Christopher Small. Musicking: The Meanings of Performing and Listening. Wesleyan University Press, 1998. - Wrigley and Emmerson [2013] William J. Wrigley and Stephen B. Emmerson. The experience of the flow state in live music performance. Psychology of Music, 2013. - Chirico et al. [2015] Alice Chirico, Silvia Serino, Pietro Cipresso, Andrea Gaggioli, and Giuseppe Riva. When music “flows”. State and trait in musical performance, composition and listening: a systematic review. Frontiers in Psychology, 2015. - Jensenius [2022] Alexander Refsum Jensenius. Sound Actions: Conceptualizing Musical Instruments. The MIT Press, 2022. - Trost et al. [2024] Wiebke Trost, Caitlyn Trevor, Natalia Fernandez, Florence Steiner, and Sascha Frühholz. Live music stimulates the affective brain and emotionally entrains listeners in real time. Proceedings of the National Academy of Sciences, 2024. - Dhariwal et al. [2020] Prafulla Dhariwal, Heewoo Jun, Christine Payne, Jong Wook Kim, Alec Radford, and Ilya Sutskever. Jukebox: A generative model for music. arXiv:2005.00341, 2020. URL https://arxiv.org/abs/2005.00341. - Forsgren and Martiros [2022] Seth Forsgren and Hayk Martiros. Riffusion - Stable diffusion for real-time music generation. 2022. URL https://web.archive.org/web/20221215132646/https://riffusion.com/about. - Agostinelli et al. [2023] Andrea Agostinelli, Timo I Denk, Zalán Borsos, Jesse Engel, Mauro Verzetti, Antoine Caillon, Qingqing Huang, Aren Jansen, Adam Roberts, Marco Tagliasacchi, et al. MusicLM: Generating music from text. arXiv:2301.11325, 2023. URL https://arxiv.org/abs/2301.11325. - Copet et al. [2023] Jade Copet, Felix Kreuk, Itai Gat, Tal Remez, David Kant, Gabriel Synnaeve, Yossi Adi, and Alexandre Défossez. Simple and controllable music generation, 2023. - Donahue et al. [2023] Chris Donahue, Antoine Caillon, Adam Roberts, Ethan Manilow, Philippe Esling, Andrea Agostinelli, Mauro Verzetti, Ian Simon, Olivier Pietquin, Neil Zeghidour, et al. SingSong: Generating musical accompaniments from singing. arXiv:2301.12662, 2023. URL https://arxiv.org/abs/2301.12662. - Chen et al. [2024] Ke Chen, Yusong Wu, Haohe Liu, Marianna Nezhurina, Taylor Berg-Kirkpatrick, and Shlomo Dubnov. MusicLDM: Enhancing novelty in text-to-music generation using beat-synchronous mixup strategies. In IEEE International Conference on Acoustics, Speech and Signal Processing, ICASSP, 2024. - Evans et al. [2024a] Zach Evans, Julian D Parker, CJ Carr, Zack Zukowski, Josiah Taylor, and Jordi Pons. Long-form music generation with latent diffusion. arXiv:2404.10301, 2024a. URL https://arxiv.org/abs/2404.10301. - Evans et al. [2024b] Zach Evans, CJ Carr, Josiah Taylor, Scott H Hawley, and Jordi Pons. Fast timing-conditioned latent audio diffusion. In ICML, 2024b. - Evans et al. [2025] Zach Evans, Julian D Parker, CJ Carr, Zack Zukowski, Josiah Taylor, and Jordi Pons. Stable audio open. In ICASSP 2025-2025 IEEE International Conference on Acoustics, Speech and Signal Processing (ICASSP), 2025. - Yuan et al. [2025] Ruibin Yuan, Hanfeng Lin, Shuyue Guo, Ge Zhang, Jiahao Pan, Yongyi Zang, Haohe Liu, Yiming Liang, Wenye Ma, Xingjian Du, et al. Yue: Scaling open foundation models for long-form music generation. arXiv:2503.08638, 2025. URL https://arxiv.org/abs/2503.08638. - Novack et al. [2025] Zachary Novack, Zach Evans, Zack Zukowski, Josiah Taylor, CJ Carr, Julian Parker, Adnan Al-Sinan, Gian Marco Iodice, Julian McAuley, Taylor Berg-Kirkpatrick, et al. Fast text-to-audio generation with adversarial post-training. arXiv:2505.08175, 2025. URL https://arxiv.org/abs/2505.08175. - Zhou et al. [2024] Xun Zhou, Charlie Ruan, Zihe Zhao, Tianqi Chen, and Chris Donahue. Local deployment of large-scale music AI models on commodity hardware. In ISMIR Late Breaking Demos, 2024. - Van Den Oord et al. [2017] Aaron Van Den Oord, Oriol Vinyals, et al. Neural discrete representation learning. In NeurIPS, 2017. - Wu et al. [2024] Haibin Wu, Xuanjun Chen, Yi-Cheng Lin, Kai-wei Chang, Ho-Lam Chung, Alexander H Liu, and Hung-yi Lee. Towards audio language modeling–an overview. arXiv:2402.13236, 2024. URL https://arxiv.org/abs/2402.13236. - Li et al. [2025] Yunpeng Li, Kehang Han, Brian McWilliams, Zalan Borsos, and Marco Tagliasacchi. SpectroStream: A versatile neural codec for general audio. arXiv:2508.05207, 2025. URL https://arxiv.org/abs/2508.05207. - Yang et al. [2023] Dongchao Yang, Jinchuan Tian, Xu Tan, Rongjie Huang, Songxiang Liu, Xuankai Chang, Jiatong Shi, Sheng Zhao, Jiang Bian, Xixin Wu, et al. UniAudio: An audio foundation model toward universal audio generation. arXiv:2310.00704, 2023. URL https://arxiv.org/abs/2310.00704. - Défossez et al. [2024] Alexandre Défossez, Laurent Mazaré, Manu Orsini, Amélie Royer, Patrick Pérez, Hervé Jégou, Edouard Grave, and Neil Zeghidour. Moshi: a speech-text foundation model for real-time dialogue. arXiv:2410.00037, 2024. URL https://arxiv.org/abs/2410.00037. - McWilliams et al. [2025] Brian Victor McWilliams, Emanuel René Jacques Orsini, Zalán Borsos, Alexandru Tudor, Damien Vincent, and Marco Tagliasacchi. Efficient generation of multimodal sequences using between-frame and within-frame machine-learned models, Jun 2025. URL https://patentscope.wipo.int/search/en/WO2025128464. - Lin et al. [2023] Liwei Lin, Gus Xia, Junyan Jiang, and Yixiao Zhang. Content-based controls for music large language modeling. arXiv:2310.17162, 2023. URL https://arxiv.org/abs/2310.17162. - Castellon et al. [2021] Rodrigo Castellon, Chris Donahue, and Percy Liang. Codified audio language modeling learns useful representations for music information retrieval. In ISMIR, 2021. - Vaswani et al. [2017] Ashish Vaswani, Noam Shazeer, Niki Parmar, Jakob Uszkoreit, Llion Jones, Aidan N. Gomez, Łukasz Kaiser, and Illia Polosukhin. Attention is all you need. In NeurIPS, 2017. - Zeghidour et al. [2021] Neil Zeghidour, Alejandro Luebs, Ahmed Omran, Jan Skoglund, and Marco Tagliasacchi. SoundStream: An end-to-end neural audio codec. IEEE/ACM Transactions on Audio Speech and Language Processing, 2021. - Huang et al. [2022] Qingqing Huang, Aren Jansen, Joonseok Lee, Ravi Ganti, Judith Yue Li, and Daniel PW Ellis. Mulan: A joint embedding of music audio and natural language. arXiv:2208.12415, 2022. URL https://arxiv.org/abs/2208.12415. - Yu et al. [2022] Jiahui Yu, Zirui Wang, Vijay Vasudevan, Legg Yeung, Mojtaba Seyedhosseini, and Yonghui Wu. CoCa: Contrastive captioners are image-text foundation models. TMLR, 2022. - Dosovitskiy et al. [2021] Alexey Dosovitskiy, Lucas Beyer, Alexander Kolesnikov, Dirk Weissenborn, Xiaohua Zhai, Thomas Unterthiner, Mostafa Dehghani, Matthias Minderer, Georg Heigold, Sylvain Gelly, Jakob Uszkoreit, and Neil Houlsby. An image is worth 16x16 words: Transformers for image recognition at scale. In ICLR, 2021. - Borsos et al. [2023] Zalán Borsos, Raphaël Marinier, Damien Vincent, Eugene Kharitonov, Olivier Pietquin, Matt Sharifi, Dominik Roblek, Olivier Teboul, David Grangier, Marco Tagliasacchi, et al. AudioLM: a language modeling approach to audio generation. IEEE/ACM transactions on audio, speech, and language processing, 2023. - Huang et al. [2018] Cheng-Zhi Anna Huang, Ashish Vaswani, Jakob Uszkoreit, Noam Shazeer, Ian Simon, Curtis Hawthorne, Andrew M Dai, Matthew D Hoffman, Monica Dinculescu, and Douglas Eck. Music Transformer. In ICLR, 2018. - Su et al. [2024] Jianlin Su, Murtadha Ahmed, Yu Lu, Shengfeng Pan, Wen Bo, and Yunfeng Liu. Roformer: Enhanced transformer with rotary position embedding. Neurocomputing, 2024. - Press et al. [2021] Ofir Press, Noah A Smith, and Mike Lewis. Train short, test long: Attention with linear biases enables input length extrapolation. arXiv:2108.12409, 2021. URL https://arxiv.org/abs/2108.12409. - Raffel et al. [2020] Colin Raffel, Noam Shazeer, Adam Roberts, Katherine Lee, Sharan Narang, Michael Matena, Yanqi Zhou, Wei Li, and Peter J Liu. Exploring the limits of transfer learning with a unified text-to-text transformer. JMLR, 2020. - Roberts et al. [2023] Adam Roberts, Hyung Won Chung, Gaurav Mishra, Anselm Levskaya, James Bradbury, Daniel Andor, Sharan Narang, Brian Lester, Colin Gaffney, Afroz Mohiuddin, et al. Scaling up models and data with t5x and seqio. Journal of Machine Learning Research, 2023. - Kim et al. [2025] Yonghyun Kim, Wayne Chi, Anastasios Angelopoulos, Wei-Lin Chiang, Koichi Saito, Shinji Watanabe, Yuki Mitsufuji, and Chris Donahue. Music arena: Live evaluation for text-to-music, 2025. - Ho and Salimans [2021] Jonathan Ho and Tim Salimans. Classifier-free diffusion guidance. In NeurIPS 2021 Workshop on Deep Generative Models and Downstream Applications, 2021. - Kreuk et al. [2023] Felix Kreuk, Gabriel Synnaeve, Adam Polyak, Uriel Singer, Alexandre Défossez, Jade Copet, Devi Parikh, Yaniv Taigman, and Yossi Adi. Audiogen: Textually guided audio generation, 2023. URL https://arxiv.org/abs/2209.15352. - Sanchez et al. [2023] Guillaume Sanchez, Honglu Fan, Alexander Spangher, Elad Levi, Pawan Sasanka Ammanamanchi, and Stella Biderman. Stay on topic with classifier-free guidance, 2023. URL https://arxiv.org/abs/2306.17806. - Manco et al. [2023] Ilaria Manco, Benno Weck, Seungheon Doh, Minz Won, Yixiao Zhang, Dmitry Bogdanov, Yusong Wu, Ke Chen, Philip Tovstogan, Emmanouil Benetos, Elio Quinton, György Fazekas, and Juhan Nam. The Song Describer dataset: a corpus of audio captions for music-and-language evaluation. In Machine Learning for Audio Workshop at NeurIPS 2023, 2023. - Cramer et al. [2019] Aurora Linh Cramer, Ho-Hsiang Wu, Justin Salamon, and Juan Pablo Bello. Look, listen, and learn more: Design choices for deep audio embeddings. In International Conference on Acoustics, Speech and Signal Processing (ICASSP), 2019. - Dannenberg [1984] Roger B Dannenberg. An on-line algorithm for real-time accompaniment. In International Computer Music Conference (ICMC), 1984. - Vercoe [1984] Barry Vercoe. The synthetic performer in the context of live performance. In International Computer Music Conference (ICMC), 1984. - Orio et al. [2003] Nicola Orio, Serge Lemouton, and Diemo Schwarz. Score following: State of the art and new developments. New Interfaces for Musical Expression (NIME), 2003. - Lewis [2000] George E Lewis. Too many notes: Computers, complexity and culture in voyager. Leonardo music journal, 2000. - Thom [2000] Belinda Thom. BoB: an interactive improvisational music companion. In International Conference on Autonomous Agents, 2000. - Pachet [2003] Francois Pachet. The Continuator: Musical interaction with style. Journal of New Music Research, 2003. - Kondak et al. [2016] Zachary Kondak, Mikayla Konst, Carli Lessard, David Siah, and Robert M Keller. Active trading with Impro-Visor. In International Workshop on Musical Metacreation, 2016. - Donahue et al. [2019] Chris Donahue, Ian Simon, and Sander Dieleman. Piano Genie. In International Conference on Intelligent User Interfaces (IUI), 2019. - Jiang et al. [2020] Nan Jiang, Sheng Jin, Zhiyao Duan, and Changshui Zhang. RL-Duet: Online music accompaniment generation using deep reinforcement learning. In AAAI, 2020. - Benetatos et al. [2020] Christodoulos Benetatos, Joseph VanderStel, and Zhiyao Duan. BachDuet: A deep learning system for human-machine counterpoint improvisation. In New Interfaces for Musical Expression (NIME), 2020. - Blanchard et al. [2024] Lancelot Blanchard, Perry Naseck, Eran Egozy, and Joseph A Paradiso. Developing symbiotic virtuosity: AI-augmented musical instruments and their use in live music performances. 2024. - Wu et al. [2025a] Yusong Wu, Tim Cooijmans, Kyle Kastner, Adam Roberts, Ian Simon, Alexander Scarlatos, Chris Donahue, Cassie Tarakajian, Shayegan Omidshafiei, Aaron Courville, et al. Adaptive accompaniment with ReaLchords. arXiv:2506.14723, 2025a. URL https://arxiv.org/abs/2506.14723. - Engel et al. [2020] Jesse Engel, Lamtharn (Hanoi) Hantrakul, Chenjie Gu, and Adam Roberts. DDSP: Differentiable digital signal processing. In ICLR, 2020. - Caillon and Esling [2021] Antoine Caillon and Philippe Esling. RAVE: A variational autoencoder for fast and high-quality neural audio synthesis. arXiv:2111.05011, 2021. URL https://arxiv.org/abs/2111.05011. - Dieleman et al. [2018] Sander Dieleman, Aaron Van Den Oord, and Karen Simonyan. The challenge of realistic music generation: modelling raw audio at scale. In NeurIPS, 2018. - Liu et al. [2025] Zihan Liu, Shuangrui Ding, Zhixiong Zhang, Xiaoyi Dong, Pan Zhang, Yuhang Zang, Yuhang Cao, Dahua Lin, and Jiaqi Wang. SongGen: A single stage auto-regressive transformer for text-to-song generation. arXiv:2502.13128, 2025. - Gong et al. [2025] Junmin Gong, Sean Zhao, Sen Wang, Shengyuan Xu, and Joe Guo. ACE-Step: A step towards music generation foundation model. arXiv:2506.00045, 2025. - Levy et al. [2023] Mark Levy, Bruno Di Giorgi, Floris Weers, Angelos Katharopoulos, and Tom Nickson. Controllable music production with diffusion models and guidance gradients. arXiv:2311.00613, 2023. - Novack et al. [2024] Zachary Novack, Julian McAuley, Taylor Berg-Kirkpatrick, and Nicholas J Bryan. DITTO: Diffusion inference-time t-optimization for music generation. In ICML, 2024. - Kumar et al. [2023] Rithesh Kumar, Prem Seetharaman, Alejandro Luebs, Ishaan Kumar, and Kundan Kumar. High-fidelity audio compression with improved RVQGAN, 2023. - Wu et al. [2025b] Shih-Lun Wu, Aakash Lahoti, Arjun D Desai, Karan Goel, Chris Donahue, and Albert Gu. Towards codec-LM co-design for neural codec language models. In Student Research Workshop at the Nations of the Americas Chapter of the Association for Computational Linguistics (NAACL-SRW), 2025b. - Zhao et al. [2022] Jingwei Zhao, Gus Xia, and Ye Wang. Beat transformer: Demixed beat and downbeat tracking with dilated self-attention. arXiv:2209.07140, 2022. URL https://arxiv.org/abs/2209.07140. - Kim et al. [2021] Minseok Kim, Woosung Choi, Jaehwa Chung, Daewon Lee, and Soonyoung Jung. KUIELab-MDX-Net: A two-stream neural network for music demixing. arXiv:2111.12203, 2021. URL https://arxiv.org/abs/2111.12203. - Engel et al. [2018] Jesse Engel, Matthew Hoffman, and Adam Roberts. Latent constraints: Learning to generate conditionally from unconditional generative models. In ICLR, 2018. ## Appendix A Related Work Our work on live music models connects to longstanding goals in computer music of live, computer-aided performance. Earlier work centered around score following: tracking live performances against known musical material to enable computer accompaniment [43, 44, 45], or systems that could both track input from human musicians and generate new symbolic material using simple probabilistic models [46, 47, 48, 49]. More recently, numerous systems have proposed live interaction with generative AI models of symbolic music [50, 51, 52, 53, 54], or small models trained on narrow music audio distributions [55, 56]. Here we aim to bridge the gap between the live interaction paradigm and the broad audio generation and control capabilities of large-scale generative AI models of music audio. Many offline music audio generation models are based off of codec LMs [18, 19]. Codec LMs are theoretically capable of streaming provided they meet two criteria: (1) the language model and codec are causal (outputs never depend on future inputs), and (2) they generate with RTF $≥ 1×$ for some chunk size $C$ (which lower bounds the control delay $D$ ). To the best of our knowledge, no existing codec LM music generation model [57, 6, 8, 9, 15, 58, 59] satisfies both criteria (most use non-causal codecs). Other music generation systems [7, 11, 12, 14, 13] are based off of latent diffusion—many achieve a throughput RTF $≥ 1×$ but generate in a non-causal fashion. Some “outpainting” methods have been proposed for latent diffusion music models [60, 61] that are related to chunked autoregression—to the best of our knowledge, these approaches have not been explored for live generation. ## Appendix B Limitations Both Magenta RT and Lyria RT present known limitations. Since the models operate on two-second chunks, user inputs for the style prompt may take two or more seconds to influence the musical output. Due to the maximum audio context window of ten seconds, the models are also unable to directly reference music that has been output further into the past. While this is sufficient to create melodies, rhythms, and chord progressions, it does not allow to automatically create longer-term song structures. ## Appendix C Additional Methodological and Training Details ### C.1 SpectroStream Here we adopt the recently proposed SpectroStream codec [20], a full-band multi-channel neural audio codec based on residual vector quantization (RVQ) [27]. Similarly to its predecessor SoundStream [27], SpectroStream is trained using a combination of adversarial and reconstruction losses. Unlike SoundStream, SpectroStream models audio in the time-frequency domain and adopts a delayed fusion mechanism, which together allow for high-fidelity audio. Specifically, SpectroStream operates on full-bandwidth stereo music at high sample rate ( $f_s=48$ kHz). Relative to other discrete codecs like the Descript Audio Codec [62], we train SpectroStream with a relatively slow framerate ( $f_k=25Hz$ ) and deeper residual quantizers ( $d_c=64$ ), consistent with recommendations from [63]. Using $10$ -bit codebooks ( $|V_c|=1024$ ), this induces an overall bandwidth of $16$ kbps. With the goal of facilitating streaming generation via an LM, we reduce the bitrate for generative modeling to $4$ kbps by generating only the first $16$ RVQ levels (coarse and medium from Figure 3), inducing a throughput target for live generation of $400$ tokens per second. ## Appendix D Lyria RT and Advanced Controls Lyria RT shares the same general architecture as Magenta RT, but with additional controls (see comparison in Table 2). Here we detail how those controls are provided as musical descriptors (D.1), how they are steered through self-conditioning and control priors (D.2), and lastly how the style embeddings are further guided through latent constraints (D.3). ### D.1 Descriptor-based Conditioning As seen in Section 4.1, contrastive audio-text embeddings obtained from models such as MusicCoCa and MuLan effectively enable control over the overall style of generated musical signals. They are not designed, however, to control fine-grained musical attributes. This section investigates the incorporation of additional conditioning features extracted from audio signals using Music Information Retrieval (MIR) methods. A full list of advanced controls for Lyria RT is provided in Table 3. | Model | Access | Style Model | SS RVQ Levels | Refinement Model | Advanced Controls | Latent Constraints | | --- | --- | --- | --- | --- | --- | --- | | Magenta RT | Open | MusicCoCa | 16 | ✗ | ✗ | ✗ | | Lyria RT | API | MuLan [28] | 64 | ✓ | ✓ | ✓ | Table 2: Comparison of Magenta RT and Lyria RT model features. | Control | Feature Extractor | | --- | --- | | Brightness | Log-mel Spectrogram Spectral Centroid and Bandwidth | | Density | Onset detection | | Key | Chroma weighted average | | Tempo | Beat prediction model [64] | | Stems On/Off | Stem separation (Bass, Drums, Vocals, Other), threshold on stem loudness | Table 3: List of controls used in training Lyria RT and method of musical descriptor feature extraction. Temporal conditioning We aim to provide precise control over the tempo of the generated stream, defined using beats-per-minute (BPM). Since we do not have access to BPM annotated audio examples, we use an off-the-shelf beat prediction model [64] to annotate our dataset, yielding an estimate for beat positions and an averaged BPM value for the entire track. We start by conditioning our model on the target BPM value rounded to the nearest integer using cross-attention. Instrumentation, timbre and harmony In addition to style steering using MuLan embeddings, we provide finer grained controls for these features. We use a source separation model [65] to extract the vocals, bass, drums and other stems from our dataset, and use those stems to generate a set of acoustic features to further condition our model. We specifically extract peak loudness, spectral centroid and bandwidth, chromas and transients separately for every stem. ### D.2 Self-conditioning Predicting conditioning tokens <details> <summary>figures/magenta_rt_global.png Details</summary>  ### Visual Description ## Diagram: Audio Processing Pipeline with Encoder-Decoder Language Model ### Overview The diagram illustrates a hierarchical audio processing system that transforms 10-second input audio into 2-second target audio using a multi-stage encoder-decoder architecture. The system employs SpectroStream encoding, MusicCoCa audio encoding, and a language model to generate style-aware audio outputs. ### Components/Axes 1. **Left Diagram (Encoder Hierarchy)** - **Encoder**: Central blue component processing audio - **RVQ Index**: Vertical axis with three levels: - Fine level (48) - Gray circles - Medium level (12) - Orange circles - Coarse level (4) - Red circles - **Frame Index**: Horizontal axis (left to right) - **SpectroStream**: Audio waveform visualization at bottom 2. **Right Diagram (Processing Flow)** - **Input Audio (10s)**: Top waveform - **Target Audio (2s)**: Bottom waveform - **SpectroStream (enc)**: Blue processing box - **MusicCoCa (audio enc)**: Green processing box - **Acoustic Context**: Red circles (5 total) - **Style Tokens**: Green squares (2 total) - **Coarse-Medium Tokens**: Orange circles (4 total) - **Encoder-Decoder Language Model**: Right-side processing component ### Detailed Analysis 1. **Encoder Hierarchy (Left)** - Three-tiered quantization system: - Fine level: 48 indices (highest resolution) - Medium level: 12 indices (intermediate resolution) - Coarse level: 4 indices (lowest resolution) - Visual representation shows decreasing granularity from gray to red circles 2. **Processing Pathways (Right)** - **Input Audio Path**: - 10s waveform → SpectroStream encoder → MusicCoCa audio encoder - Produces: 5 acoustic context tokens (red) + 2 style tokens (green) - **Target Audio Path**: - 2s waveform → SpectroStream encoder - Output: 4 coarse-medium tokens (orange) - **Language Model Integration**: - Combines acoustic context and style tokens - Generates coarse-medium tokens for target audio ### Key Observations 1. **Temporal Compression**: 10s input compressed to 2s target (5x reduction) 2. **Multi-Resolution Encoding**: Three distinct quantization levels in encoder 3. **Token Composition**: - Acoustic context dominates (5 tokens) - Style tokens provide secondary influence (2 tokens) - Final output uses coarse-medium tokens (4 tokens) 4. **Color-Coded Components**: - Red = Acoustic context - Green = Style tokens - Orange = Coarse-medium tokens - Blue = SpectroStream encoder - Green = MusicCoCa encoder ### Interpretation This system demonstrates a hierarchical approach to audio generation where: 1. **Input Processing** extracts both acoustic features (through SpectroStream) and stylistic elements (via MusicCoCa) 2. **Token Generation** creates a hybrid representation combining: - Detailed acoustic information (acoustic context) - Stylistic preferences (style tokens) 3. **Output Generation** uses coarse-medium tokens to create compressed audio while preserving: - Temporal structure (from input audio) - Stylistic characteristics (from style tokens) - Acoustic properties (from acoustic context) The architecture suggests a balance between preserving input characteristics and enabling creative transformation through style tokens. The use of multiple quantization levels in the encoder allows for efficient representation of audio features at different resolutions, while the language model component enables context-aware generation of the target audio. </details> Figure 3: Overall architecture of Magenta RT. Coarse acoustic tokens and quantized style tokens corresponding to 10s of audio context are concatenated and fed to the encoder part of our model. The decoder then predicts coarse and medium acoustic tokens corresponding to the the following 2 seconds. <details> <summary>figures/self_conditioned_model.png Details</summary>  ### Visual Description ## Flowchart: Audio Processing Pipeline for Target Audio Generation ### Overview The diagram illustrates a multi-stage audio processing pipeline that transforms a 10-second input audio into a 2-second target audio through encoding, tokenization, and refinement processes. The workflow involves two encoders, descriptor extraction, and a refinement model. ### Components/Axes 1. **Input Audio (10s)** - Represented as a waveform at the top-left. - Feeds into two encoders: - **SpectroStream (enc)** (blue box) - **MuLan (audio enc)** (green box) 2. **Output Tokens** - **Acoustic Context**: Red circles (5 tokens) - **Style Tokens**: Green squares (2 tokens) 3. **Enc-Dec Model** - Processes acoustic context and style tokens into: - **Control Tokens**: Teal circles (7 tokens) - **Coarse-Medium Tokens**: Red (2) + Orange (3) circles (5 tokens) 4. **Refinement Stage** - Coarse-medium tokens refined into **Fine Tokens**: Gray circles (6 tokens) 5. **Target Audio (2s)** - Generated from fine tokens, shown as a waveform at the top-right. 6. **MIR Descriptors** - Gray box connecting input audio to control tokens, indicating metadata extraction. ### Detailed Analysis - **Color-Coded Components**: - Blue: SpectroStream encoder (spectral analysis) - Green: MuLan encoder (audio-specific features) - Red: Acoustic context tokens - Teal: Control tokens (high-level audio structure) - Orange: Coarse-medium tokens (intermediate representation) - Gray: Fine tokens (detailed audio features) - **Flow Direction**: Input audio → Encoders → Tokenization → Enc-Dec Model → Refinement → Target audio. ### Key Observations 1. **Dual Encoding**: Input audio is processed by two encoders (SpectroStream and MuLan) to capture complementary features. 2. **Token Hierarchy**: - Acoustic context (red) and style tokens (green) are combined for initial encoding. - Control tokens (teal) represent high-level audio structure. - Coarse-medium tokens (red/orange) bridge control and fine tokens. - Fine tokens (gray) are the final refined representation for target audio. 3. **Refinement Step**: Explicitly separates coarse-to-fine processing, emphasizing precision in target audio generation. ### Interpretation The pipeline demonstrates a hierarchical approach to audio generation: - **Input Encoding**: SpectroStream and MuLan extract distinct acoustic and stylistic features, ensuring robust representation. - **Tokenization**: Reduces raw audio to symbolic tokens (acoustic/style) for model compatibility. - **Control and Refinement**: Control tokens guide the Enc-Dec Model, while refinement progressively sharpens the representation (coarse → fine tokens). - **MIR Integration**: Metadata descriptors (MIR) likely contextualize audio features for better alignment with target specifications. This architecture suggests applications in audio synthesis, style transfer, or compression, where precise control over acoustic and stylistic elements is critical. The explicit refinement step highlights the importance of iterative processing for high-fidelity output. </details> Figure 4: Diagram of Lyria RT training / predicting conditioning tokens. Coarse acoustic tokens and quantized MuLan tokens are concatenated and fed to the encoder part of our language model. Control tokens, including BPM, stem balance, brightness, density and chromas (see Section D.1) are predicted first by the decoder, followed by coarse and medium level acoustic tokens. Finally, a small refinement model predicts the fine-scale acoustic tokens as described in Section D.4. Given an acoustic token sequence $x$ and a conditioning token sequence $c$ , it is common practice to learn the conditional distribution $p(x|c)$ in a supervised fashion, and expose the conditioning tokens to the user during inference to make the generation controllable. This approach has several drawbacks: 1. User defined conditioning might be out of distribution, especially when conditioning tokens are dependent on each other (e.g., natural temporal evolution of a conditioning signal). 1. Unconditional generation can be achieved through training-time conditioning dropout, however the resulting samples are empirically worse than those from a model trained unconditionally from scratch. To address these issues, we introduce self-conditioning where we aim at learning the joint distribution $p(x,c)=p(x|c)p(c)$ . This can be achieved by prefixing the acoustic tokens with the conditioning tokens, and train the model using a causal mask, as seen in Figure 4. Intuitively, this allows to use the resulting model either unconditionally, by first sampling the conditioning tokens and then sampling from the conditional distribution, or let the user override some or all of the conditioning tokens to gain some control over the generation. While this helps bridge the quality gap with unconditional models, this methods expects the user to provide conditioning tokens aligned with the underlying prior distribution $p(c)$ . This is a reasonable assumption for scalar conditions like tempo, but is significantly harder for complex conditions such as stems loudness or chromas. Control priors We leverage the fact that we already have an estimation of the distribution underlying the conditioning tokens $p(c)$ to implement soft controls. Soft controls are implemented through the definition of a prior distribution over the conditioning tokens that is used to steer the sampling process. In practice, we map simple controls to categorical priors that we combine with the next token predicted logits to steer the sampling process, as shown in Figure 5. <details> <summary>x3.png Details</summary>  ### Visual Description ## Diagram: Token Generation Process with Bias Modeling ### Overview The diagram illustrates a token generation process involving three key components: 1. **Token Logit Calculations** (top section) 2. **Control Tokens** (left section) 3. **Acoustic Tokens** (right section) It demonstrates how user-defined priors modify next-token predictions to produce biased outputs, with a clear flow from control to acoustic tokens. --- ### Components/Axes #### Top Section: Token Logits - **Bar Charts**: - **Blue Bars**: "next token logits" (distribution of predicted token probabilities) - **Red Bars**: "user defined prior" (uniform distribution with high probability for specific tokens) - **Purple Bars**: "biased logits" (result of multiplying blue × red distributions) - **Equation**: `next token logits × user defined prior = biased logits` #### Bottom Section: Token Flow - **Control Tokens**: - Three identical yellow circles (uniform input tokens) - Positioned left of the vertical divider - **Acoustic Tokens**: - First token: Purple circle (biased output) - Subsequent tokens: White circles (standard outputs) - Positioned right of the vertical divider - **Arrows**: - Upward arrow from control tokens to top section (input to logit calculation) - Downward arrow from top section to acoustic tokens (logit to output mapping) --- ### Detailed Analysis #### Token Logits - **Next Token Logits (Blue)**: - Bimodal distribution with peaks at positions 2 and 4 (approximate values: 0.3 and 0.25 probability). - **User Defined Prior (Red)**: - Uniform distribution with a sharp peak at position 1 (probability ~0.8) and negligible probabilities elsewhere. - **Biased Logits (Purple)**: - Dominated by position 1 (probability ~0.24, calculated as 0.3 × 0.8). - Remaining probability mass distributed across positions 2–4 (reduced compared to original logits). #### Token Flow - **Control Tokens**: - Three identical tokens suggest a fixed input sequence (e.g., prompt tokens). - **Acoustic Tokens**: - First token (purple) aligns with the biased logits' peak at position 1. - Subsequent white tokens indicate a return to standard generation after the initial bias. --- ### Key Observations 1. **Bias Amplification**: - The user-defined prior (red) strongly biases the first acoustic token toward position 1, overriding the original logits' preference for positions 2–4. 2. **Token Sequence Dynamics**: - Control tokens (uniform) → Biased first acoustic token → Standard subsequent tokens. 3. **Logit Interaction**: - Multiplication of logits (not probabilities) implies a multiplicative bias mechanism rather than additive. --- ### Interpretation This diagram models a **biased token generation system** where: - **User-defined priors** act as a "soft constraint" on token selection, disproportionately favoring specific tokens (e.g., position 1). - The **multiplicative bias mechanism** (logit × prior) reduces diversity in early token predictions but allows recovery in later tokens. - The **control-to-acoustic flow** suggests a hierarchical process: 1. Fixed input tokens (control) 2. Biased prediction of the first output token 3. Standard generation for subsequent tokens **Notable Anomaly**: The biased logits (purple) show a 33% reduction in total probability mass compared to the original logits (blue), indicating potential information loss due to over-constraining the model. **Technical Implication**: This architecture could represent a **controlled text generation system** where users inject priors to steer outputs (e.g., for safety or style), but risks introducing unintended biases or limiting expressiveness. </details> Figure 5: Control priors for self-conditioning. The predicted logits (likelihood) for the control tokens are shifted by a user defined prior dictated by the control values. These are combined to give the final posterior logits that are used for sampling, and steer the model outputs in the direction of the user controls. ### D.3 Constraining Style Embeddings As mentioned in Section 2.2, we train the language models conditioned on style embeddings computed from the raw audio waveform. This is in contrast to the inference setup where we use text based embeddings. While similar, due to the contrastive training of MuLan, the audio and text embedding spaces are not completely overlapping. Indeed, early experiments showed that a two layer MLP is sufficient to classify embeddings as text-based or audio-based with $>90\$ accuracy. In practice, we notice a non-negligible drop in audio quality when predicting from text based embeddings compared to audio embeddings, which is likely due to the mismatch between both embedding spaces. Furthermore, biases exist between specific text genres and audio recording quality. To address these issues, impose a latent constraint [66], by building a dataset comprised of MuLan embeddings from three sources (text, low-quality audio, and high-quality audio) and training a small GAN to transform text based embeddings into high quality audio embeddings using an adversarial setup. Both the generator and discriminator are a 4-layer MLP. The discriminator is trained to separate ground truth high-quality audio embeddings (i.e. real) embeddings from the generator outputs (i.e. fake embeddings). The generator is trained to optimize the following two objectives: being classified as real by the classifier while staying close to the original base embedding. We use the Hinge GAN objective, and use cosine similarity between input and generated embeddings as a regularization strategy. <details> <summary>x4.png Details</summary>  ### Visual Description ## Diagram: Text Embedding Generation and Discrimination System ### Overview The diagram illustrates a machine learning system architecture for generating and evaluating text embeddings. It depicts a feedback loop between a generator and discriminator, with explicit labels for input/output data types and quality metrics. ### Components/Axes 1. **Generator** (central rectangle): - Input: "text, high / low quality embeddings" - Output: "high quality embeddings" 2. **Discriminator** (right rectangle): - Input: "high quality embeddings" (from generator) - Output: "real / fake" classification 3. **Feedback Loop**: - Arrows indicate bidirectional interaction between generator and discriminator - "regularization" label on feedback path from discriminator to generator ### Content Details - **Input Data Flow**: - Text embeddings (both high and low quality) enter the generator - Generator processes inputs to produce "high quality embeddings" - **Output Data Flow**: - Generated embeddings sent to discriminator - Discriminator classifies outputs as "real" (matches high-quality standards) or "fake" - **Regularization Mechanism**: - Discriminator's output ("real/fake") feeds back to generator - This loop likely represents adversarial training to improve generator performance ### Key Observations 1. The system explicitly distinguishes between input text embedding qualities (high/low) 2. The generator's sole output is labeled as "high quality embeddings" 3. The discriminator's binary classification ("real/fake") suggests a GAN-like adversarial training setup 4. Regularization arrow indicates continuous model refinement through feedback ### Interpretation This architecture represents a Generative Adversarial Network (GAN) adapted for text embedding generation. The generator's dual input (high/low quality embeddings) suggests: 1. **Training Objective**: Convert low-quality text embeddings to high-quality representations 2. **Evaluation Mechanism**: Discriminator acts as a quality gatekeeper, providing feedback to refine the generator 3. **Regularization Role**: The feedback loop prevents overfitting by forcing the generator to produce increasingly realistic embeddings The system's design implies a focus on improving embedding quality through adversarial training, where the discriminator's "real/fake" judgments drive iterative improvements in the generator's output. The explicit labeling of input quality variations indicates awareness of data heterogeneity in the training process. </details> Figure 6: Training the latent constraint model ### D.4 Refinement Model As seen in Figure 4, Lyria RT has an additional refinement model to predict 48 additional fine-scale RVQ SpectroStream tokens per a frame. This model is trained separately from the core language model, and is a very small MLP that quickly autoregressively predicts the remaining tokens. This provides a slight bump in audio fidelity at the cost of longer inference. Because Magenta RT is focused towards real-time control on less powerful hardware, we reserve the refinement model for Lyria RT and find it to be a good compromise of audio fidelity and compute efficiency. ## Appendix E Audio Injection <details> <summary>x5.png Details</summary>  ### Visual Description ## Diagram: Audio Processing System Architecture ### Overview The diagram illustrates a multi-stage audio processing system with encoder-decoder architecture. It shows the flow of acoustic context through style tokens, coarse-medium token generation, and audio output generation. The system includes explicit components for acoustic context modeling, style token processing, and audio synthesis. ### Components/Axes 1. **Acoustic Context**: - Top row labeled "acoustic context" with 6 circular tokens (A-F) in red-to-pink gradient - Bottom row labeled "next acoustic context" with 6 circular tokens (C-H') in lighter red-to-pink gradient 2. **Style Tokens**: - Two blue square tokens labeled "style tokens" between acoustic context rows 3. **Coarse-Medium Tokens**: - Four yellow circular tokens (G-H) arranged in 2x2 grid 4. **Processing Units**: - "Encoder" (blue trapezoid) receiving next acoustic context - "Decoder" (blue parallelogram) producing output audio - "Enc-Dec Model" (central processing unit) connecting style tokens to coarse-medium tokens 5. **Audio Streams**: - "User audio (2s)" (green waveform) - "Mix audio" (combined waveform) - "Output audio (2s)" (final waveform) ### Spatial Grounding - **Top Section**: Acoustic context (A-F) → Style tokens → Coarse-medium tokens (G-H) - **Bottom Section**: Next acoustic context (E'-H') → Encoder → Mix audio - **Central**: Enc-Dec Model bridges style tokens and coarse-medium tokens - **Right Side**: Decoder produces output audio from mixed inputs ### Detailed Analysis 1. **Token Progression**: - Acoustic context (A-F) transforms into style tokens (blue squares) - Style tokens feed into Enc-Dec Model to generate coarse-medium tokens (G-H) - Next acoustic context (E'-H') flows through encoder to create mix audio 2. **Color Coding**: - Red-to-pink gradient for acoustic context tokens (darker = earlier in sequence) - Blue for style tokens and processing units - Yellow for coarse-medium tokens - Green for user audio input 3. **Temporal Flow**: - Left-to-right progression through processing stages - Feedback loop from next acoustic context to encoder ### Key Observations 1. The system uses a hybrid approach combining discrete tokens (A-F) with continuous audio processing 2. The Enc-Dec Model acts as a critical bridge between symbolic representation (style tokens) and audio generation 3. User audio input (2s) is mixed with processed acoustic context before final output 4. Output audio duration matches input duration (2s) suggesting real-time processing capability ### Interpretation This architecture demonstrates a sophisticated audio synthesis system that: 1. **Context Modeling**: Maintains acoustic context through token sequences (A-F → E'-H') 2. **Style Transfer**: Encodes style information through discrete tokens (blue squares) 3. **Audio Generation**: Uses encoder-decoder architecture for temporal audio modeling 4. **Personalization**: Incorporates user audio input for adaptive synthesis The system appears designed for applications requiring: - Real-time audio generation - Style transfer capabilities - Context-aware synthesis - User input integration The color-coded token progression suggests a hierarchical processing approach where symbolic representations (A-F) are gradually transformed into audio-ready features (G-H) through the Enc-Dec Model. The mixing of user audio indicates potential for interactive or adaptive audio generation systems. </details> Figure 7: Steering with a live audio stream using audio injection. At each inference step, user input audio is mixed with model output audio, and the mix is encoded as coarse SpectroStream tokens. These context tokens are passed as the input for the next inference step, so the model predicts the continuation following its own output plus the user’s input. To allow the user to continuously steer generation via a live audio stream, we propose an audio steering mechanism that we call audio injection. At each generation step, we mix the user’s input audio with the model’s output, tokenize the resulting mix, and feed this as the model’s context for the next generation. This is illustrated in Figure 7. Note, user audio is never played back directly. Rather, the model predicts the continuation of a past context that includes the user audio. Depending on the specific audio injected and the target style, the model may “choose” to repeat or transform the user audio, or may be influenced by its features (dynamics, melody, harmony). To better control the influence of the user audio on the model output, we use classifier free guidance [38]. Specifically, we perform inference on both a positive example where the audio context includes the mixed-in user input, as well as a negative example where the audio context consists of only the model’s output. The final logits used for sampling are calculated as a linear combination of the positive and negative logits, where higher guidance weight ( $w$ ) pushes towards the positive conditioning: $(1+w)·Logits_pos-w·Logits_neg$ Live audio prompt To further increase the effect of the user input, we add a “live” audio prompt that periodically updates based on the MusicCoCa audio embedding of the most recent user input audio. Increasing the weight of this prompt within overall prompt mixture has the effect of steering the model to output music in a style that is consistent with the user audio (e.g., containing guitar, if the user is playing guitar). One challenge to audio injection is that there is unavoidable latency between the input and output streams. In our testing setup, we observed a delay of several seconds between the input and output. Thus, if the user is performing along with the model, we will only have around $7$ seconds of input audio ready to mix with the model’s most recent $10$ seconds of output, to feed as the next context. We consider two solutions to this issue, which are suited to two different interaction styles: “free” mode, and “looper” mode. In free mode, the user’s input audio is mixed directly with the “concurrent” output (i.e. matching what the user heard while they were performing), but no input is mixed into the final stretch of context. In looper mode, we assume the music follows a “looping” structure at a known tempo, and mix input from the previous loop into the current context, filling the entire context window with input audio. We discuss these approaches and their tradeoffs below. “Free” mode We mix the user’s input in at its original timing (aligning with what the user heard when they performed it), and mix in silence for that portion of the context for which the streamer has not yet received the inputs. Since the inputs are mixed at their logical location, this control mechanism is intuitive, and the streams can be mixed without knowledge of the tempo or song structure. However, one disadvantage is the user’s contribution will suddenly drop to silence for the final portion of the model’s context. This “cutting out” can weaken the effect of the conditioning, as the most recent context tends to have the largest effect on generation. It may also lead to unwanted artifacts, since the user’s audio may be clipped to silence mid-phrase. We can soften these artifacts by fading the input to silence. However, the fade out may still be unexpected, and doesn’t correspond to the user’s true performance. “Looper” mode For music with fixed tempo and a relatively short “looping” structure (e.g., a repeating 4-bar chord progression), we can overcome the latency issue by mixing in user audio from the previous loop, as opposed to the current one. This interaction is similar to a “looper” pedal (where audio is looped to build layered composition); however instead of playing the past audio back verbatim, we mix it into the model’s context window, where it may influence the model’s continuation. Compared to “free” mode, this has the advantage of allowing us to fill the entire context window with user audio, which we find increases the likelihood of the model being influenced by that audio. However there are several downsides to “looper” mode. First, the control is less intuitive than “free” mode, as the effect of the user input is delayed by one loop. This requires the user to plan ahead, and also limits what musical forms can be expressed. Second, the user needs to specify the loop length (e.g., $8$ beats at $120$ BPM), and we need to guarantee the model output actually respects this chosen tempo and loop length. This can be achieved by tempo conditioning (Section D.1), or by adjusting the loop length in real time to match the model output. However if the model ever drifts from the set tempo, the mixed user input will be misaligned with the model output, which can lead to unexpected results. Throughout development, we prototyped audio injection with musicians of different backgrounds, including instrumentalists (guitar, piano, drums), a producer, and a live electronic DJ. User responses were varied, with some finding it inspiring, and others finding it too unpredictable. ## Appendix F User Study To understand how live music models impact users’ creative expression and process, we conducted a study with five music enthusiasts. We were primarily interested in probing how the continually streaming nature of the model impacted their state of flow and creative expression as well as their perceived level of control of the model’s generated music. <details> <summary>x6.png Details</summary>  ### Visual Description ## Screenshot: Music Production Software Interface ### Overview The image depicts a digital audio workstation (DAW) interface with two primary sections: 1. **Section A (Top)**: Audio effect toggles and sliders. 2. **Section B (Bottom)**: Parameter controls, waveform visualization, and playback controls. ### Components/Axes #### Section A (Top) - **Audio Effect Toggles**: - `OUD` (Green slider, 70% position) - `Digital Hardcore` (Purple slider, 30% position) - `Disco Bagpipes` (Orange slider, 50% position) - **Buttons**: - `Add a prompt...` (Text input field) - `More` (Dropdown with options: `Fiddle`, `Huge Drop`, `Chill`, `Bongos`, `Salsa`, `Spacy Synths`, `Zither`) #### Section B (Bottom) - **Parameter Controls**: - `Density` (Slider with `+` and `-` icons) - `Brightness` (Slider with `+` and `-` icons) - `Chaos` (Slider with `+` and `-` icons) - `Drums`, `Bass`, `Other` (Toggle buttons) - **Waveform Visualization**: - Multi-colored waveform (Red, Green, Blue, Purple) - Playhead (White vertical line at 50% position) - **Playback Controls**: - `Pause` (|| icon) - `Play` (▶️ icon) - `Stop` (■ icon) - `BPM` (Text label) - `Key` (Text label) - `Share` (Icon) ### Detailed Analysis - **Section A**: - The `OUD` effect is the most activated (70% slider), suggesting emphasis on traditional instrumentation. - `Digital Hardcore` is minimally applied (30%), while `Disco Bagpipes` is moderately used (50%). - The `More` dropdown includes genre-specific instruments, indicating customization options. - **Section B**: - The waveform shows a complex audio track with overlapping instruments (colors likely represent different tracks). - Playhead at 50% suggests mid-track editing. - Parameter sliders (`Density`, `Brightness`, `Chaos`) are unadjusted (default position). ### Key Observations 1. **Contrast in Effects**: Traditional (`OUD`) vs. electronic (`Digital Hardcore`, `Disco Bagpipes`) effects are both present but used at varying intensities. 2. **Unadjusted Parameters**: Sliders for `Density`, `Brightness`, and `Chaos` remain at default, implying no active modulation. 3. **Waveform Complexity**: Multiple colors in the waveform suggest layered tracks, but the legend for color mapping is not visible. ### Interpretation This interface is designed for granular audio manipulation, blending traditional and electronic elements. The lack of parameter adjustments in Section B suggests the user is in an initial editing phase, focusing on effect selection rather than fine-tuning. The absence of a visible legend for the waveform colors limits clarity on track separation. The `Share` button implies collaboration features, while the `BPM` and `Key` labels hint at tempo and key signature tools for composition. **Note**: No numerical data or explicit trends are present beyond slider positions. The interface prioritizes visual and interactive controls over textual data representation. </details> Figure 8: Screenshot of the interface used in our study. User interface As part of the study, we used the MusicFX DJ interface developed for the Lyria RT model, http://labs.google/musicfx which includes the advanced controls described in Section D.1. The interface, shown in Figure 8, allows users to input their own natural language prompts (e.g. “oud” or “digital hardcore”), each accompanied by a slider that adjusts its respective influence on the generated music. The system also provides prompt suggestions for inspiration. In addition to steering the model through these prompts, users are also given three high-level controls: density, which adjusts how busy the music should be; brightness, which adjusts the presence of higher frequency sounds; and chaos, which controls how unpredictable the generated music should be. To begin streaming music, users press play, and as they make adjustments to the prompts or high-level controls, the music adjusts accordingly. Finally, users can adjust the key and BPM of the produced music, as well as clear the music history if they want to start fresh. Study structure The overall structure of the user study was as follows: (1) participants were given a short demo of the user interface, (2) they then interacted with the interface for 20 minutes, while thinking aloud and explaining their thought process, and (3) afterwards, they were interviewed on their experience. During the task, participants were asked to simply explore the user interface, treat it as an “interactive radio” and discover new sounds (Section F.2). Afterwards, the interview consisted of questions that probed their thoughts on the impact of the model’s continually streaming nature and their perceived level of control (Section F.3). The total time commitment of the study was 30 minutes. ### F.1 Findings Impact of continuous streaming The continuous nature of the generated music significantly shaped the participants’ creative experience; it gave them something to respond to and improvise with, often drawing comparisons to collaborative and traditional music-making processes. P1 compared interacting with the continual stream to improvising with fellow musicians: “It’s not so different from playing with other people… as you play you react to each other non-verbally to the music. I can see three people playing instruments along with this, steering the model together”. This sentiment was echoed by two other musicians and composers, P4 and P5, who felt the experience mirrored their own composition workflows of creating loops, reacting to them, and incrementally layering additional tracks on software like Ableton. For example, P5 started off with warm acoustic guitar, and then subsequently layered in flute and harp. When asked about her process, P5 explained that the acoustic guitar prompt led to a feeling of “walking in a forest after some rain”, and she added in flute to “mimic the sound of birds chirping”, as well as the harp to further extend the feeling of peace she was building. A key element of the live model’s continuous stream that users appreciated was its ability to introduce subtle, ongoing variations, even when they had not changed the prompts. This element of gentle evolution was highly valued by P3, who appreciated the opportunity for serendipitous discovery it provided: “I wait to see if the model will produce something interesting… the model might have settled on something that was originally boring, but then jump to something more exciting”. Echoing this point, P4 explained that the subtle variations were “nice in that it [the music] doesn’t feel repetitive”, but at the same time, he noted that these variations would also make him feel like he had “lost something”, if there was something he wanted to keep. Sometimes a melody or texture he liked would suddenly drop out and he felt he had no way to get it back or reinforce it. On control and influencing the model In regards to controlling this continuous stream of music, participants felt that the prompts let them broadly steer the model, rather than afford them specific, direct control. P3 felt like he was “guiding and the model is meeting you half way”, while P4 described it as “throwing ingredients in the pot, and the AI is cooking it up”. This perceived level of control, however, changed significantly according to the number of prompts already included. For instance, P1 noted that while the model could be “extremely accurate” with one or two prompts, it became less predictable as more were added. Similarly, P4 felt he had a “good amount of control” when creating an initial sound, but “a lot less control” when trying to make nuanced, real-time adjustments, where additional prompts could suddenly “take over the track” and completely change the sound. Summary Overall, the live model’s continuous output fostered a collaborative and improvisational creative process, allowing users to react to and build upon the AI’s output as they would with a fellow musician. While participants appreciated the model’s evolving variations for sparking serendipitous discovery, they ultimately felt more like a guide than a director, possessing the ability to broadly steer the music but lacking the precise control needed to refine it or prevent the loss of desired elements. ### F.2 Participant Instructions We report below the instructions given to participants at the beginning of each session: Introduction: Hi, thanks for taking the time to participate in this study. During this study, we’ll be creating some sounds with a live, generative music tool. We’ll spend about 15 minutes using the tool, where you’ll be asked to think aloud and explain your thought process as you use it. And afterwards we’ll have a 5-10 minute exit interview on your experience. Any questions so far? Task: Please point your browser to: https://labs.google/fx/tools/music-fx-dj and share your screen (as well as audio). For the next 20 minutes we’ll be playing around with this tool. As you try out its features, please think-aloud and describe your thought process and reactions. Imagine you’re a composer using this tool to explore new sounds or inspiration for a new project. ### F.3 Exit Interview Questions After completing the task, participants were asked the following questions: Overall experience: (1) Could you describe your overall experience using the tool? What was surprising, exciting, or frustrating? Exploration process: (1) Describe a moment when you discovered a particularly interesting or unexpected sound or musical direction. What did you do to get there? (2) What was your thought process behind choosing new prompts or adjusting the sliders? (3) How did the continuous nature of the music influence your exploration or creative process? Prompt history: (1) How would you describe how the music changed and evolved over the course of the session? (2) How did you feel the history of your prompts shaped the music the model produced later on? Agency & control: (1) Could you describe the level of control you felt over the music that was generated? (2) How would you describe your partnership with AI in creating the music you heard? ## Appendix G Prompt Transitions Prompts used for the “Prompt Transition” eval in Section 3.2.2. Transitions are linear interpolations of text embeddings every 10 seconds over 60 seconds (i.e., [ $0.0$ , $1.0$ ], [ $0.2$ , $0.8$ ], [ $0.4$ , $0.6$ ], [ $0.6$ , $0.4$ ], [ $0.8$ , $0.2$ ], [ $1.0$ , $0.0$ ]). | Accordion $→$ Ambient | Accordion $→$ Dirty Synths | | --- | --- | | Accordion $→$ Minimal Techno | Afrobeat $→$ Synthpop | | Alternative Country $→$ Dirty Synths | Alto Saxophone $→$ Dulcimer | | Ambient $→$ Gypsy Jazz | American Folk $→$ Afrobeat | | Balalaika Ensemble $→$ Fuzz Guitar | Banjo $→$ Jamaican Dub | | Baroque $→$ Djembe | Baroque $→$ West Coast Hip Hop | | Bass Clarinet $→$ Orchestral Score | Bassoon $→$ Classic Rock | | Blues Rock $→$ Balalaika Ensemble | Blues Rock $→$ Glitch Hop | | Blues Rock $→$ Marching Band | Bongos $→$ Lute | | Bongos $→$ Viola Ensemble | Bouzouki $→$ Indie Folk | | Breakbeat $→$ Bongos | Breakbeat $→$ Synthpop | | Cavaquinho $→$ Flamenco Guitar | Cello $→$ Classic Rock | | Charango $→$ Guitar | Clavichord $→$ Precision Bass | | Congo Drums $→$ Vaporwave | Contemporary R&B $→$ Harpsichord | | Contemporary R&B $→$ Pop Punk | Country $→$ Breakbeat | | Country $→$ Renaissance Music | Delta Blues $→$ Smooth Pianos | | Didgeridoo $→$ Charango | Didgeridoo $→$ Kalimba | | Dirty Synths $→$ Cavaquinho | Dirty Synths $→$ Ukulele | | Disco Funk $→$ Hard Rock | Djembe $→$ Dirty Synths | | Djembe $→$ Psychedelic | Doo Wop $→$ Bossa Nova | | Doo Wop $→$ Industrial Rock | Doo Wop $→$ Tango | | Drum & Bass $→$ Gypsy Jazz | Drum & Bass $→$ Harp | | Drum & Bass $→$ Trance | Electro Swing $→$ Lute | | Electro Swing $→$ Pipa | Erhu $→$ Mandolin | | Fiddle $→$ Hard Rock | Fiddle $→$ Surf Rock | | Flamenco Guitar $→$ Bass Clarinet | Funk Metal $→$ Pipa | | Funky $→$ Koto | Fuzz Guitar $→$ Soprano Saxophone | | Fuzz Guitar $→$ Synth Pads | Fuzz Guitar $→$ TR-909 Drum Machine | | Fuzz Guitar $→$ Trance | Glitch Hop $→$ Synthpop | | Glockenspiel $→$ Clavichord | Hang Drum $→$ Jamaican Dub | | Hang Drum $→$ Steel Drum | Hard Bop Jazz $→$ Tango | | Hard Rock $→$ Balalaika Ensemble | Hard Rock $→$ Hurdy-gurdy | | Harp $→$ R&B (Rhythm and Blues) | Harpsichord $→$ Congo Drums | | Harpsichord $→$ Koto | Harpsichord $→$ Trance | | Heavy Metal $→$ Chiptune | Heavy Metal $→$ Jamaican Dub | | Hurdy-gurdy $→$ Cavaquinho | Hurdy-gurdy $→$ Classic Rock | | Hurdy-gurdy $→$ Gypsy Jazz | Hyperpop $→$ Bongos | | Indian Classical $→$ Tuba | Indie Pop $→$ Ska | | Industrial Rock $→$ Accordion | K-Pop $→$ Soprano Saxophone | | Klezmer $→$ Glockenspiel | Klezmer $→$ Hang Drum | | Klezmer $→$ Tuba | Latin Jazz $→$ Erhu | | LinnDrum $→$ Synth Pads | Lo-Fi Hip Hop $→$ Bagpipes | | Lute $→$ Balalaika Ensemble | Lyre $→$ Latin Jazz | | Lyre $→$ Techno | Mandolin $→$ Synth Pads | | Marching Band $→$ Chamber Music | Mbira $→$ Hard Bop Jazz | | Neo-Soul $→$ Marimba | Neo-Soul $→$ Psychedelic Rock | | Orchestral Score $→$ Mellotron | Piano Ballad $→$ Garage Rock | | Piano Ballad $→$ LinnDrum | Pipa $→$ Chiptune | | Pop Punk $→$ Ambient | Pop Punk $→$ Baroque | | Pop Punk $→$ Hurdy-gurdy | Post-Punk $→$ Chillout | | Precision Bass $→$ Accordion | Progressive House $→$ Irish Folk | | Progressive House $→$ Mariachi | Psychedelic $→$ Moombahton | | --- | --- | | Psychedelic Rock $→$ Sitar | R&B (Rhythm and Blues) $→$ Mariachi | | Renaissance Music $→$ Warm Acoustic Guitar | Sarod $→$ Afrobeat | | Sarod $→$ Funk Drums | Sarod $→$ Smooth Pianos | | Sitar $→$ Marimba | Ska $→$ Dubstep | | Ska $→$ Fiddle | Smooth Pianos $→$ Garage Rock | | Steel Drum $→$ Post Rock | Surf Rock $→$ Fiddle | | Surf Rock $→$ Gypsy Jazz | Synth Pads $→$ Mellotron | | Thrash Metal $→$ Tabla | Trance $→$ Djembe | | Vaporwave $→$ Ragtime Piano | Warm Acoustic Guitar $→$ Indie Electronic | | Warm Acoustic Guitar $→$ Klezmer | Warm Acoustic Guitar $→$ LinnDrum | | West Coast Hip Hop $→$ Indian Classical | Woodwinds $→$ Accordion | | Woodwinds $→$ Psychedelic Rock | Zither $→$ Dreamy |
